Description
COLORado 1-Tri IP is an IP66-rated LED wash with 14 intense, calibrated tri-colored LEDs. This outdoor-rated workhorse is an ideal front light as high-efficiency optics and tri-colored LEDs eliminate multicolored shadows while selectable dimming curves ensure compatibility with an older non-LED rig. Optional (20° and 60° x 1°) color blending filters further enhance this unit’s outstanding performance. COLORado 1-Tri IP also includes an attachable gel frame holder.
~Built-in auto and custom programs recalled via DMX and Master/Slave
~RGB color mixing via DMX or manually
~Color temperature presets, from 2800 to 10000 K
~5-pin DMX input/output connections
~16-bit dimming of master dimmer and individual colors
~Selectable, smooth dimming curves for programming versatility
~LED display with password protection
~IP66 rated for outdoor water and dust protection
~M12 GORE valve for assured internal equalization
~Built-in auto and custom programs recalled via DMX and Master/Slave
~Simple and complex DMX channel profiles for programming versatility
~Double-bracket yoke doubles as floor stand
~Tri-color RGB LEDs
Specifications:
OPTICAL
Light Source: 14 LEDs (tri-color RGB) 3 W, (700 mA), 50,000 hours life expectancy, Color Temperature (range): 2800 to 10000 K, Beam Angle: 15°, Field Angle: 28°, Illuminance (total): 806 lux @ 5 m, PWM Frequency: 900 Hz.
DYNAMIC EFFECTS
Dimmer: Electronic, Shutter/Strobe: Electronic, Strobe Rate: 0 to 20 Hz, Standalone Color Mixing: Yes, Color Temperature Presets: Yes, Dim Modes: 8, Built-in Automated Programs: Yes, Customizable Programs: Yes, Recall Custom Programs: Yes.
CONSTRUCTION / PHYSICAL
Dimensions: 8 x 9.7 x 9.5 in (202 x 246 x 242 mm), Weight: 9.6 lb (4.4 kg), Exterior Color: Black, Housing Material: Aluminum die-cast, Accessory Holder/Gel Frame Size: 7.5 in (191 mm).
CONNECTIONS
Power Connection: Edison plug to proprietary IP66 input power cord (65 in/1,651 mm), Power Input: Proprietary IP66, Power Output: Proprietary IP66, Cable Length: 5 ft (1.5 m), Cable Length (signal extension): 16.4 ft (5 m), Cable Length (power extension): 16.4 ft (5 m).
CONTROL
Control Protocol: DMX, DMX Channels: 3, 4, 5, 9 or 13, Modes/Personalities: 6 personalities (ARC.1, HSV, AR1.D, AR1.S, TOUR, TR16).
ELECTRICAL
60 Hz (auto-ranging), Power Linking: 14 units @ 120 V; 24 units @ 208 V; 26 units @ 230 V, Power and Current: 87 W, 0.73 A @ 120 V, 60 Hz, Power and Current: 91 W, 0.44 A @ 208 V, 60 Hz, Power and Current: 93 W, 0.40 A @ 230 V, 50 Hz.
CERTIFICATIONS / QUALIFICATIONS
CE, MET, IP Rating: IP66, outdoor/wet, with pressure equalizing M12 GORE valve
Exact Contents:
x4 COLORado 1-Tri IP
x4 Local plug to proprietary IP66 input power cord
x4 Male and female 5-pin XLR DMX to proprietary IP66 adapters
x3 Gel frame holder (7.5 in/191 mm accessories)
x4 Safety cabels with carabiner
x4 Protection plate
x1 Flight case
Delivery notes
Collection only (if delivery is required then job lot can be sent at buyers expense via pallet track).
Location: Wimbledon, London
Contact notes
David - 0207 622 0495
| Price: |
£1000 +VAT |
| Quantity: |
4 — Price is for all units. |
| Ref#: |
8164ADCDEA09 |
